The Mitsubishi ASX 2.2 DI-D AWD produced from 2012 to 2016 offers a diesel powertrain with 150 hp, an automatic transmission and all-wheel drive. Below you find all technical data regarding the powertrain, performance, weights, consumption and more.
Also view:
| Total powertrain | |
| Fuel type | Diesel |
| System power | 110 kW (150 hp) |
| System power range | 3500 rpm |
| System torque | 360 Nm |
| System torque range | 1500 – 2750 rpm |
| Transmission type / Gears | Automatic / 6 |
| Drivetrain | All-wheel drive |
| Combustion engine | |
| Engine type / Number of cylinders | In-line / 4 |
| Valves per cylinder | 4 |
| Displacement | 2268 cc |
| Bore | 86.00 mm |
| Stroke | 97.60 mm |
| Compression ratio | 14.9 :1 |
| Acceleration 0–100 km/h | 10.8 s |
| Top speed | 190 km/h |
| Front tyre size (standard) | 215/60 R17 |
| Rear tyre size (standard) | 215/60 R17 |
| Front wheel size (standard) | 17" |
| Rear wheel size (standard) | 17" |
| Front brake type | Ventilated discs |
| Rear brake type | Discs |
| Front brake diameter | 294 mm |
| Rear brake diameter | 302 mm |
| Kerb weight | 1520 kg |
| Gross vehicle weight | 2060 kg |
| Roof load capacity | 80 kg |
| Towing capacity (braked) | 1400 kg |
| Fuel consumption | |
| NEDC consumption combined | 5.8 L/100 km |
| NEDC consumption low | 7.1 L/100 km |
| NEDC consumption high | 5.1 L/100 km |
| Fuel tank capacity | 60 L |
| CO₂-emissions | |
| NEDC CO₂ combined | 153 g/km |
