The Mazda CX-60 2.5 e-Skyactiv PHEV produced from 2022 to today offers a plug-in hybrid petrol powertrain with 328 hp, an automatic transmission and all-wheel drive. Below you find all technical data regarding the powertrain, performance, weights, consumption and more.
Also view:
| Total powertrain | |
| Fuel type | Plug-in hybrid |
| System power | 241 kW (328 hp) |
| System power range | 6000 rpm |
| System torque | 500 Nm |
| System torque range | 4000 rpm |
| Transmission type / Gears | Automatic / 8 |
| Drivetrain | All-wheel drive |
| Combustion engine | |
| Engine type / Number of cylinders | In-line / 4 |
| Valves per cylinder | 4 |
| Displacement | 2488 cc |
| Bore | 89.00 mm |
| Stroke | 100.00 mm |
| Compression ratio | 13.0 :1 |
| Power combustion engine | 141 kW (192 hp) |
| Engine power range | 6000 rpm |
| Torque combustion engine | 261 Nm |
| Engine torque range | 4000 rpm |
| Electric motors | |
| Power of electric motor 1 | 129 kW (175 hp) |
| Torque of electric motor 1 | 270 Nm |
| Acceleration 0–100 km/h | 5.8 s |
| Top speed | 200 km/h |
| Front tyre size (standard) | 235/60 R18 |
| Rear tyre size (standard) | 235/60 R18 |
| Front wheel size (standard) | 7.5J x 18" |
| Rear wheel size (standard) | 7.5J x 18" |
| Front brake type | Ventilated discs |
| Rear brake type | Ventilated discs |
| Front brake diameter | 347 mm |
| Rear brake diameter | 328 mm |
| Kerb weight | 1984 kg |
| Gross vehicle weight | 2667 kg |
| Maximum front axle load | 1244 kg |
| Maximum rear axle load | 1523 kg |
| Roof load capacity | 100 kg |
| Towing capacity (unbraked) | 750 kg |
| Towing capacity (braked) | 2500 kg |
| Battery | |
| Battery type | Lithium-ion |
| Battery weight | 176 kg |
| Battery gross capacity | 17.80 kWh |
| Electric consumption | |
| WLTP consumption combined | 22.7 – 23.1 kWh/100 km |
| Electric range | |
| Electric range | 63 – 64 km |
| Electric range (city) | 69 – 71 km |
| Fuel consumption | |
| WLTP consumption combined | 1.4 L/100 km |
| Fuel tank capacity | 50 L |
| CO₂-emissions | |
| WLTP CO₂ combined | 31 – 33 g/km |
| Emission class | Euro 6e |
